espec ethirteen Carbon Rear Wheel Enduro 29"
WH4LRA-105
" Specials " e*spec e*thirteen Race Carbon Rear Wheel Enduro …
e*spec components are designed to support the additional weight and torque of ebikes so you can ride exactly how you want and then some.
Whether you're after the responsive handling and weight savings of carbon wheels, or just one of those riders who is tired of wheel failures and are ready to enjoy hand built wheel quality to ride as aggressively with confidence, e*Spec Race Carbon Wheels were made for you. e*thirteen e*spec Race wheels start with a custom carbon layup and rim profile derived from our years of developing World Cup Downhill wheels that our teams can trust to achieve their championship dreams.
e*spec Race Carbon Wheels are available in 29” and 27.5" sizes. The 29" size comes with a 30mm inner width optimized for 2.3"-2.6" tire profiles. The 27.5 options come with 35mm inner width which amplifies tire stability and retention for wider e-Bike tires (like our 2.7" Zeppelin), and makes for a perfect rear wheel choice on MIxed or Mullet e-bike builds.
PRODUCT SPEC
Axle Steel axle w/pinch bolt
Color Black w/Sticker
Drilling 28h front, 32h rear
Engagement 6 degree
ERD
27.5: 553
29: 594
Features e*spec hubs still have 6-degree engagement, but use an outboard bearing to better support the driver body and disperse loads. Mechanism is triple-sealed, and uses a steel axle w/pinch bolt to decrease deflection.
Freehub Mount XD™ or Shimano™ Microspline™ Driver
Hub e*spec rear hub, specially designed for eBike use.
Included Wheels w/driver body (taped w/tubeless valves installed), spoke x3, nipple x3, nipple washer x3,
Material World Cup developed carbon
Size 27.5, 29
Spokes/Nipples Custom J-bend, triple-butted spokes w/alloy nipples and nipple washers
Weight
Single wheel weight w/valves + tape
Front 27.5 & 29: 941g
Rear 27.5 XD Driver:1264g
Rear 29 XD Driver: 1289g
Width
27.5 Wheel(s): 35mm internal width
29 Wheel(s): 30mm internal width
